SPM01 1.7-inch Bluetooth Cycling Navigation Display

Technical specifications

SPM01 cycling navigation display with supplier-listed 1.7-inch tft, 360*360px and 900mAh battery capacity. Navigation is phone-connected; the hardware table lists no built-in GPS. Contact YAGUFE for samples, OEM packaging, confirmed specifications, delivery terms and a wholesale quotation. Protection ratings and battery duration are supplier-listed and subject to use conditions.

Model

SPM01

Display (supplier listed)

1.7-inch TFT, 360*360px

Case material (supplier listed)

Aluminum alloy shell+PC+ABS bottom shell

Main chipset

AC7012/A6

Wireless specification

Bluetooth 5.3+3.0, operating frequency 2402-2480MHz

Memory

640KB+16Mb

Memory expansion

not support

RF antenna

FPC

Heart-rate sensor

not supported

Blood-pressure function (supplier listed)

not supported

Blood oxygen (supplier listed)

not supported

Barometer

not supported

GPS

not supported

Geomagnetic sensor

not supported

Body-temperature function (supplier listed)

not supported

G-sensor

Support

Compass

not supported

Gyroscope

not supported

ECG function (supplier listed)

not supported

Screen size

1.7 inches

Screen resolution

360*360

Screen material

TFT

Touch control

Full screen touch

Touch construction

OGS

Cover glass

panda

Battery type

polymer

Battery capacity

900mAh

Battery documents (supplier listed; request copies)

MSDS/UN38.3 certification

Charging method

TYPE-C cable charging

Charging time (supplier listed)

1.5 hours (theoretical time)

Buttons

1 (supports one knob)

Button function

Swtich

Speaker

1217 1.5W

LED lights

4 LED

Protection rating (supplier listed)

IP68

Watch-face / UI configuration

Customize UI

Companion app / configuration

SMARTTIME Pro

Languages

Simplified Chinese, English, etc., default English

Sports modes (supplier listed)

Cycling, motorcycle riding

Functions described by supplier

Google navigation, sport mode (bike riding, motorcycle riding), weather, message notifications, call reminders (answer/hang up), ride history, warning light (external flashlight), sound switch, screen duration, volume settings, brightness adjustment, automatic brightness adjustment, language settings, Do Not Disturb mode, password lock, restart, factory reset, shutdown, QR code

Product image

Supplier product reference. Confirm final appearance and branding with a sample.

Specifications are based on the supplied catalog or quotation. Playback and wireless range depend on use conditions. Confirm the selected configuration, colors, packaging, samples and applicable MOQ before ordering. Product appearance is shown for reference; no YAGUFE logo has been added to the product image.
