B02 Series Mini Bluetooth 5.1 OBD2 Adapter with Multiple Chipset and Protocol Options

Explore B02 Series automotive electronics sourcing.

Compact Bluetooth 5.1 adapter
B02 / B02-K / B02-KD / B02-V / B02-Z
7-protocol and 9-protocol options

Wholesale MOQConfirm with sales

OEM MOQConfirm with sales

Price / lead timeBy quotation

Samples / brandingAsk for availability

Supplier-provided configuration. Please confirm the exact model, color, samples and wholesale terms with sales.

MODEL DETAILS

Technical specifications

B02 Series Mini Bluetooth 5.1 OBD2 Adapter with Multiple Chipset and Protocol Options. Compact Bluetooth 5.1 adapter. B02 / B02-K / B02-KD / B02-V / B02-Z. 7-protocol and 9-protocol options. Request the selected configuration, vehicle or fluid compatibility, samples, wholesale pricing and OEM options from YAGUFE. Specifications are translated from the supplied catalog; confirm the ordered version and supporting documents.

Model: B02 Series
B02 variants: B02: separate 7-protocol and 9-protocol versions pictured; YM1130 is the general family controller reference. Confirm exact version.
B02-K variant: 9-protocol option; imported 25K80 dual-board design, as annotated
B02-KD variant: 9-protocol option; imported 25K80 dual-board design; supplier additionally lists diesel and gasoline applications for this variant only. Confirm exact vehicle support.
B02-V variant: 7-protocol option; YM1121 second-generation controller; third-party app use noted. The catalog explicitly lists no environmental / qualification documents for this version.
B02-Z variant: 7-protocol option; YM1121 second-generation controller. The catalog explicitly lists no environmental / qualification documents for this version; confirm app support.
App support: YMOBD with 25 languages is stated in the general family description; verify app / platform for the chosen version, especially B02-V and B02-Z.
Family reference: Shared dimensions, weight, voltage and packing are catalog family references. Confirm each ordered variant and protocol; appearance alone does not establish its configuration.
Customization: Supplier-listed options: packaging, color, logo, model name and functions. Confirm selected options, sample, MOQ, lead time and documentation with YAGUFE. Bluetooth name and MAC address options are listed.
Bluetooth version: 5.1
Material: ABS
Operating voltage (listed): 8V-28V
Operating current (listed): 6mA-12mA
Operating temperature (listed): -20 C to 85 C
Storage temperature: -20 C to 70 C
Vehicle / application reference: 12V gasoline vehicles: US 1996 onward / Europe 2003 onward, as listed by supplier. Confirm make, model, year and protocol before ordering.
Product dimensions: 49 x 26 x 30mm
Net product weight: 18g
Retail box dimensions: 100 x 64 x 26mm
Packed gross weight: 34g
Master carton dimensions: 530 x 290 x 270mm
Carton quantity (not MOQ): 200pcs
Carton gross weight: 7.2kg/7.9kg(B02-K)
Documents listed by supplier: Supplier lists FCC / CE / RoHS in the general family table, but B02-V and B02-Z explicitly have no environmental / qualification documents listed. Request exact variant documents.

Specifications are based on the supplied catalog or quotation. Playback and wireless range depend on use conditions. Confirm the selected configuration, colors, packaging, samples and applicable MOQ before ordering. Product appearance is shown for reference; no YAGUFE logo has been added to the product image.

Source with confidence.

Include quantity, destination market, plug type, packaging, and delivery date. Request the current specification sheet, actual photos, test documents, and sample terms before ordering.
