B08 Bluetooth 5.1 OBD2 Adapter with 7-Protocol and 9-Protocol Options

Technical specifications

B08 Bluetooth 5.1 OBD2 Adapter with 7-Protocol and 9-Protocol Options. Bluetooth 5.1 / YMOBD app. 7-protocol or 9-protocol versions. YM1130 family controller. Request the selected configuration, vehicle or fluid compatibility, samples, wholesale pricing and OEM options from YAGUFE. Specifications are translated from the supplied catalog; confirm the ordered version and supporting documents.

Model

B08

Controller

YM1130, as listed in the family description

Protocol versions

Separate 7-protocol and 9-protocol options are pictured. Confirm exact protocol version; the general 9-protocol description does not apply to every option.

App

YMOBD app with 25 languages; confirm selected variant and platform

Family reference

Shared parameter table reproduced from the catalog. Confirm variant-specific specification and app support.

Customization

Supplier-listed options: packaging, color, logo, model name and functions. Confirm selected options, sample, MOQ, lead time and documentation with YAGUFE. Bluetooth name and MAC address options are listed.

Material

ABS

Bluetooth version

5.1

Operating voltage (listed)

7V-30V

Operating current (listed)

40mA-50mA

Operating temperature (listed)

-20 C to 85 C

Storage temperature

-20 C to 70 C

Vehicle / application reference

12V gasoline vehicles: US 1996 onward / Europe 2003 onward, as listed by supplier. Confirm make, model, year and protocol before ordering.

Product dimensions

90 x 46 x 25mm

Net product weight

40g

Retail box dimensions

100 x 64 x 26mm

Packed gross weight

54g

Master carton dimensions

530 x 290 x 270mm

Carton quantity (not MOQ)

200pcs

Carton gross weight

11.2kg

Documents listed by supplier

FCC / CE / RoHS listed by supplier; request documents for the exact model, configuration and destination market.

Specifications are based on the supplied catalog or quotation. Playback and wireless range depend on use conditions. Confirm the selected configuration, colors, packaging, samples and applicable MOQ before ordering. Product appearance is shown for reference; no YAGUFE logo has been added to the product image.
